AT-S105 Management Software Web Browser User’s Guide
223
Bridge/Spanning Tree/RSTP
Global RSTP Status Disabled Disabled Enabled/Disabled
Bridge Protocol Version RSTP RSTP STP-Compatible/RSTP
Bridge Priority 0x8000 0x8000 0x0000-0xF000, step:0x1000
Bridge Hello Time 2 seconds 2 seconds 1-9 seconds
Bridge Maximum age
time 20 seconds 20 seconds 6-28 seconds
Bridge Forward Delay 15 seconds 15 seconds 11-30 seconds
Bridge/Spanning Tree/RSTP Basic Port
Port STP Status Enabled Enabled Enabled/Disabled
Port Priority 128 128 0-240, step:16
Port Path Cost 200,000 200,000 1-200,000,000
Bridge/Spanning Tree/RSTP Advanced Port
Port STP Status Enabled Enabled Enabled/Disabled
Port Edge Status FALSE FALSE TRUE/FALSE
Port PtoP Status AUTO AUTO AUTO/TRUE/FALSE
Bridge/Trunk Config/Trunking
Trunk Status Disabled Disabled Enabled/Disabled
Bridge/Trunk Config/LACP Group Status
LACP key none none 1-10
MAX Number of ports in
a group 8 ports 8 ports -
MAX number of groups
in a unit 10 groups 10 groups -
Table 11. AT-S105 Management Software Default Settings (Continued)
Parameter
AT-FS750/24POE
Default Setting
AT-FS750/48
Default Setting
Specifications
