11. CONTROL INPUTS:
Internal 10 KW pull-up to +5 VDC. V
IL
= 1.0 V
MAX,
V
IH
= 4.0 V
MIN.
Response time = 10 msec nominal, 30 msec maximum.
INPUTS
SWITCH CONNECTIONS
RUN
Momentary N.O.
FAST STOP
Momentary N.C.
RAMP STOP
Momentary N.C.
JOG
Sustained N.O.
OPEN LOOP
Maintained
USER INPUTS (4)
Function Specific
12. OUTPUTS:
DRIVE ENABLE, ALARM 1, and ALARM 2:
Solid state, current sinking NPN Open collector transistor.
V
CE
= 1.1 V
SAT
@ 100 mA maximum, V
OH
= 30 VDC maximum.
(Internal zener diode protection.)
Response Time:
Drive Enable: 10 msec nominal; 30 msec maximum.
ALARM 1&2: Programmable
NORMAL: 1 sec nominal, 2 sec maximum.
FAST: 20 msec nominal, 40 msec maximum.
ISOLATED DRIVE OUTPUT: Jumper selectable internal/external
reference 5 mA MAX.
Internal Reference: Pot adjustable from 0 to 5 VDC minimum span
through 0 to 15 VDC maximum span.
External Reference: 15 VDC maximum. (positive polarity only).
ISOLATION: 2300 Vrms for 1 minute
250 V working
13. ENVIRONMENTAL CONDITIONS:
Operating Temperature: 0° to 50°C
Storage Temperature: -40° to 70°C.
Operating And Storage Humidity: 85% max. relative humidity
(non-condensing) from 0°C to 50°C
Altitude: Up to 2000 meters
14. CERTIFICATIONS AND COMPLIANCES:
ELECTROMAGNETIC COMPATIBILITY
Immunity to EN 50082-2
Electrostatic discharge
EN 61000-4-2
Level 2; 4 Kv contact
Level 3; 8 Kv air
Electromagnetic RF fields
EN 61000-4-3
Level 3; 10 V/m
80 MHz - 1 GHz
Fast transients (burst)
EN 61000-4-4
Level 4; 2 Kv I/O
Level 3; 2 Kv power
RF conducted interference
EN 61000-4-6
Level 3; 10 V/ms
150KHz - 80 MHz
Power frequency magnetic fields
EN 61000-4-8
Level 4; 30 A/m
Simulation of cordless telephone
ENV 50204
Level 3; 10 V/m
900 MHz ± 5MHz
200 Hz, 50% duty cycle
Emissions to EN 50081-2
RF interference
EN 55011
Enclosure class A
Power mains class A
Note: Refer to the EMC Installation Guidelines for additional information.
15. CONSTRUCTION: High impact plastic case with clear viewing
window. The front panel meets NEMA 4X/IP65 requirements for indoor
use when properly installed. Panel gasket and mounting clips included.
Installation Category II, Pollution Degree 2.
16. WEIGHT: 1.5 lbs. (0.68 Kg).
