Red Lion MDC - Manual (Page 30)

-28-
USER SETTINGS
MASTER MODE: FOLLOWER MODE:
USER SETPOINTS: USER SETPOINTS:
S1 S1
S2 S2
R1 R1
R2 R2
DISPLAY 1 DISPLAY 1
LINE 1 LINE 1
LINE 2 LINE 2
DISPLAY 2 DISPLAY 2
LINE 1 LINE 1
LINE 2 LINE 2
DISPLAY 3 DISPLAY 3
LINE 1 LINE 1
LINE 2 LINE 2
DISPLAY 4 DISPLAY 4
LINE 1 LINE 1
LINE 2 LINE 2
SCALING:
PPR LD
MAX RPM LD
FACTORY SETTINGS COMMON TO MASTER AND FOLLOWER MODES:
USER SETPOINTS: USER INPUTS:
JOG SPD User Input 1
JOG RAMP User Input 2
AL-1 User Input 3
AL-2 User Input 4
GAIN User Key F1
User Key F2
SCALING:
PPR FB OPTIONS:
MAX RPM FB Operator Access:
DSP DP S1 YES NO
DSP UNIT S2 YES NO
R1 YES NO
ALARM OUTPUTS: R2 YES NO
ALARM 1: JOG SPD YES NO
Alarm Type JOG RAMP YES NO
Phase AL-1 YES NO
Latched/Boundary AL-2 YES NO
Update GAIN YES NO
SPT SCROLL YES NO
ALARM 2:
Alarm Type
Phase No Feedback Detection: YES NO
Latched/Boundary
Update
Stop Mode Status
DISPLAY:
Scroll Speed
