-57-
APPENDIX “D” - GEMINI DUAL COUNTER MODE FUNCTION COMMAND CODE SUMMARY
CODE MODE DESCRIPTION COMMENTS
65 CNTR A DECIMAL POINT & LEAD ZERO BLANKING
(+) Leading Zero Blanking Enabled
(-) Leading Zero Blanking Disabled*
+/-1 No Decimal Point
+/-2 Decimal Point Right of Digit 2
+/-3 Decimal Point Right of Digit 3
+/-4 Decimal Point Right of Digit 4
+/-5 Decimal Point Right of Digit 5
+/-6 Decimal Point Right of Digit 6
66 “OPERATOR ACCESSIBLE FUNCTIONS” MODES “PGM DIS” Terminal connected to “Comm”
(+) Reset Button & “RST” Terminal Enabled Front panel reset can be independently disabled by using
DIP switch.
(-) Reset Button & “RST” Terminal Disabled* This mode has no affect on the “RST A” terminal which is
always enabled.
+/-1 No Functions Enabled
+/-2 Preset Programming Enabled
+/-3 Scale Factor Programming Enabled
+/-4 Preset & Scale Factor Programming Enabled
+/-5 Preset & Counter Load Programming Enabled
+/-6 Preset, Scale Factor & Cnter Load Programming Enabled
1 PRESET 1 Up to +/-999999
2 PRESET 2 Up to +/-999999
3 Display A COUNTER A SCALE FACTOR Up to +/-5.9999
3 Display B COUNTER B SCALE FACTOR Up to +/-5.9999
E & Display A COUNTER A COUNTER LOAD VALUE Up to +/-999999. Counter Load value is NOT saved in
+/- memory when power is removed.
E & Display B COUNTER B COUNTER LOAD VALUE Up to +/-999999. Counter Load value is NOT saved in
+/- memory when power is removed.
* Polarity sign is displayed in front of the identifier, a (-) sign is displayed, a (+) sign is not.
