-56-
APPENDIX “D” - GEMINI DUAL COUNTER MODE FUNCTION COMMAND CODE SUMMARY
CODE MODE DESCRIPTION COMMENTS
56 COUNTER B RESET MODES (Cont’d)
+/-1 Manual Reset to Zero Automatically selected when boundary mode is used [52,6].
+/-2 Manual Reset to Preset**
+/-3 Automatically Reset to Zero after Timed Output**
+/-4 Automatically Reset to Preset after Timed Output**
+/-5 Automatically Reset to Zero at Preset** Counter resets as soon as Output is activated.**
+/-6 Automatically Reset to Preset at Zero**
61 COUNTER A RESET MODES
(+) Maintained Unit remains reset as long as reset is activated.
(-) Momentary* Unit will reset and start counting again, even if reset is
still activated.
+/-1 Manual Reset to Zero Automatically selected when boundary mode is used [52,6].
+/-2 Manual Reset to Preset 1
+/-3 Automatically Reset to Zero after Timed Output 1
+/-4 Automatically Reset to Preset 1 after Timed Output 1
+/-5 Automatically Reset to Zero at Preset 1 Counter resets as soon as Output 1 is activated.
+/-6 Automatically Reset to Preset 1 at Zero
64 COUNTER A SCALE MULTIPLIER
1 1
2 0.1
3 0.01
4 0.001
* Polarity sign is displayed in front of the identifier, a (-) sign is displayed, a (+) sign is not.
** For the Gemini 4200, all reset to preset modes reset to preset 2 and Timed Output refers to Output 2.
