-55-
APPENDIX “D” - GEMINI DUAL COUNTER MODE FUNCTION COMMAND CODE SUMMARY
CODE MODE DESCRIPTION COMMENTS
51 OUTPUT ASSIGNMENT
(+) Preset Tracking Disabled
(-) Preset Tracking Enabled* Preset 1 tracks Preset 2
+/-1 Output 1 to Counter A, Output 2 to Counter B
+/-2 Outputs 1 & 2 to Counter B Automatically selects [61 1]
52 OUTPUT 1 TERMINATION MODES
(+) Normal Phase Output normally “OFF”, turns “ON” at preset.
(-) Reverse Phase* Output normally “ON”, turns “OFF” at preset.
+/-1 Terminate at Output 2 Start (Gemini 4200 only) Only available when [51 2]
+/-2 Terminate at Output 2 End (Gemini 4200 only) Only available when [51 2]
+/-3 Terminate at Manual Reset
+/-4 Terminate at Manual Reset End
+/-5 Terminate after Timed Output
+/-6 Boundary Automatically selects code [61 1] if [51 1]
53 TIMED OUTPUT 1 VALUE Range 0.01 to 599.99 sec.
54 GEMINI 4200 OUTPUT 2 TERMINATION MODES
(+) Normal Phase Output normally “OFF”, turns “ON” at preset.
(-) Reverse Phase* Output normally “ON”, turns “OFF” at preset.
+/-1 Terminate at Output 1 Start Only available when [51 2]
+/-2 Terminate at Output 1 End Only available when [51 2]
+/-3 Terminate at Manual Reset
+/-4 Terminate at Manual Reset End
+/-5 Terminate after Timed Output 2
+/-6 Boundary Automatically selects code [56 1].
55 GEMINI 4200 TIMED OUTPUT 2 VALUE Range 0.01 to 599.99 sec.
56 COUNTER B RESET MODES
(+) Maintained Unit remains reset as long as reset is activated.
(-) Momentary* Unit will reset and start counting again, even if reset is
still activated.
* Polarity sign is displayed in front of the identifier, a (-) sign is displayed, a (+) sign is not.
