-50-
CODE MODE DESCRIPTION COMMENTS
41 UNIT PERSONALITY (-)Loads factory set code values*
+/-1 Counter/Rate* Rate Display → value (A)/Counter → Display value (B)
42 RESET BUTTON & TERMINAL ACTUATION MODES
1 Reset Rate Output For Rate, reset only affects the output and does not
2 Reset Counter change the displayed value. For Counter, reset affects the
3 Reset Rate Output & Counter output as well as the count value
43 INPUTS 1 & 2 RESPONSE MODES
1 Count with Inhibit Input 1 = Cnt & Rate, Input 2 = Inh for Cnt.
2 Count with Up/Down Control Input 1 = Cnt & Rate, Input 2 = Up/Dn for Cnt
3 Add/Subtract Input 1 = Add & Rate, Input 2 = Subtract
4 Separate Inputs Input 1 = Rate, Input 2 = Counter
5 Quadrature Input 1 = Cnt & Rate, Input 2 = Quadrature
6 Quadrature x4 Input 1 = Cnt, Quad, & Rate, Input 2 = Cnt & Quad
44 COUNTER NUMBER OF COUNT EDGES Cannot be programmed in Quad x4.
1 Single Edge Counting (x1) Count on falling edge of count input
2 Double Edge Counting (x2) Count on both edges of count input.
45 COUNTER SCALE MULTIPLIER
1 1
2 0.1
3 0.01
4 0.001
46 CNTR DECIMAL POINT & LEAD ZERO BLANKING
- (+) Leading Zero Blanking Enabled
- (-) Leading Zero Blanking Disabled *
+/-1 No Decimal Point
+/-2 Decimal Point Right of Digit 2
+/-3 Decimal Point Right of Digit 3
+/-4 Decimal Point Right of Digit 4
+/-5 Decimal Point Right of Digit 5
+/-6 Decimal Point Right of Digit 6
* Polarity sign is displayed in front of the identifier, a (-) sign is displayed, a (+) sign is not.
APPENDIX “D” - GEMINI COUNTER/RATE MODE FUNCTION COMMAND CODE SUMMARY
