APPENDIX “D” - GEMINI COUNTER/RATE MODE FUNCTION COMMAND CODE SUMMARY
CODE MODE DESCRIPTION COMMENTS
56 COUNTER RESET MODES (Cont’d)
+/-1 Manual Reset to Zero Automatically selected when outputs are configured for rate
[51 3] or when boundary mode is used [54 6].
+/-2 Manual Reset to Preset**
+/-3 Automatically Reset to Zero after Timed Output**
+/-4 Automatically Reset to Preset after Timed Output**
+/-5 Automatically Reset to Zero at Preset** Counter resets as soon as Output is activated.**
+/-6 Automatically Reset to Preset at Zero**
61 RATE RIGHT-HAND DUMMY ZEROS
1 1 Dummy Zero
2 2 Dummy Zeros
3 3 Dummy Zeros
4 No Dummy Zeros
62 RATE CONVERSION FACTOR
1 Rate Per Second (x1)
2 Rate Per Minute (x60)
3 Rate Per Hour (x3600)
63 RATE MINIMUM UPDATE TIME
1 0.5 Sec minimum/1 Sec maximum
2 1 Sec minimum/2 Secs maximum
3 2 Secs minimum/4 Secs maximum
4 4 Secs minimum/8 Secs maximum
5 8 Secs minimum/16 Secs maximum Maximum rate = 7500 cps
6 16 Secs minimum/32 Secs maximum Maximum rate = 3250 cps
64 RATE SCALE MULTIPLIER
1 1000
2 100
3 10
4 1
* Polarity sign is displayed in front of the identifier, a (-) sign is displayed, a (+) sign is not.
** For the Gemini 4200, all reset to preset modes reset to preset 2 and Timed Output refers to Output 2.
