-54-
APPENDIX “D” - GEMINI DUAL COUNTER MODE FUNCTION COMMAND CODE SUMMARY
CODE MODE DESCRIPTION COMMENTS
41 UNIT PERSONALITY (-)Loads factory set code values*
+/-2 Dual Counter* Counter A→Display value (A)/Counter B→Display value (B)
42 RESET BUTTON & TERMINAL ACTUATION MODES
1 Reset Counter A Reset affects the outputs as well as the displayed value.
2 Reset Counter B
3 Reset Counter A & B
43 INPUTS 1 & 2 RESPONSE MODES
1 Count With Inhibit Input 1 = Cnt A & Cnt B, Input 2 = Inh.
2 Count With Up/Down Control Input 1 = Cnt A & Cnt B, Input 2 = Up/Dn.
3 Add/Subtract Input 1 = Add, Input 2 = Subtract
4 Separate Inputs Input 1 = Counter A, Input 2 = Counter B
5 Quadrature Input 1 = Cnt A & Cnt B, Input 2 = Quadrature
6 Quadrature x4 Input 1 = Cnt & Quad, Input 2 = Cnt & Quad.
44 COUNTER A & B NUMBER OF COUNT EDGES Cannot be programmed in quadrature x4.
1 Single Edge Counting (x1) Count on falling edge of count input.
2 Double Edge Counting (x2) Count on both edges of count input
45 COUNTER B SCALE MULTIPLIER
1 1
2 0.1
3 0.01
4 0.001
46 CNTR B DECIMAL POINT & LEAD ZERO BLANKING
(+) Leading Zero Blanking Enabled
(-) Leading Zero Blanking Disabled*
+/-1 No Decimal Point
+/-2 Decimal Point Right of Digit 2
+/-3 Decimal Point Right of Digit 3
+/-4 Decimal Point Right of Digit 4
+/-5 Decimal Point Right of Digit 5
+/-6 Decimal Point Right of Digit 6
* Polarity sign is displayed in front of the identifier, a (-) sign is displayed, a (+) sign is not.
