A Fibre Channel port entry consists of the following sequence of objects
qsrFcPortRole QsrPortRole
qsrFcPortIndex Unsigned32
qsrFcPortNodeWwn PhysAddress
qsrFcPortWwn PhysAddress
qsrFcPortId PhysAddress
qsrFcPortType Unsigned32
qsrFcLinkStatus QsrLinkStatus
qsrFcLinkRate QsrLinkRate
qsrFcPortRole
QsrPortRole Syntax
Not accessible Access
Operational role of this port: Fibre Channel protocol (FCP) mode or frame shuttle mode. Description
qsrFcPortIndex
Unsigned32 Syntax
Not accessible Access
A positive integer indexing each Fibre Channel port in a specified role. Description
qsrFcPortNodeWwn
PhysAddress Syntax
Read only Access
World wide name of the node that contains this port. Description
qsrFcPortWwn
PhysAddress Syntax
Read only Access
World wide name for this port. Description
qsrFcPortId
PhysAddress Syntax
Read only Access
Interface's 24-bit Fibre Channel address identifier. Description
qsrFcPortType
Unsigned32 Syntax
Read only Access
Type of Fibre Channel port, as indicated by the use of the appropriate value assigned by the
IANA. The Fibre Channel port types registry maintained by IANA is located at:
www.iana.org/
assignments/fc-port-types
Description
qsrFcLinkStatus
QsrLinkStatus Syntax
Management Information Base 107
