Complete static in-path route configuration only if your network requires additional
static network routing rules.
To set a static, in-path
network route
1. Click the Setup Appliances tab to expand the Setup Appliances menu.
2. Click Appliance Specific in the left menu to expand the Appliance Specific
configuration menu.
3. Click Routing: In-Path in the left menu to display the In-Path Routing page.
Figure 3-29. Setup: In-Path Routing Page
4. Use the controls to complete the configuration, as described in the following table.
5. To save the settings permanently, click Save.
To revert to the running configuration, click Reset.
Control
Description
Settings will be applied to
appliance
Select the appliance for which you want to view or modify the configuration from the
drop-down list.
Select interface
Select an in-path interface from the drop-down list, for example, inpath0_0.
Add New Route
Gateway. Type the IP address for the gateway in the text box. The gateway must be in the
same network as the Primary or Auxiliary interface.
Netmask. Type the subnet mask in the text box.
Destination. Type the IP address in the text box.
Add Route. Click this button to add the entry to the list.
Remove Selected Routes. To remove a route, click the check box next to the entry and
click Remove Selected Routes.
