NIC Port LabelingTerminology Note
Labeling for the NIC ports can vary. To avoid confusion, the table below outlines the
different labels for the NIC ports.
2 Internal health LED Green = System health is normal.
Amber = System is degraded.
Red = System critical.
Off = System health is normal (when in standby
mode).
3 NIC 1 link/activity LED Green = Network link exists.
Flashing green = Network link and activity
exist.
Off = No link to network exists.
4 NIC 2 link/activity LED Green = Network link exists.
Flashing green = Network link and activity
exist.
Off = No link to network exists.
5 Drive activity LED Green = Drive activity is normal.
Amber = Drive failure occurred.
Off = No drive activity.
6 Power On/Standby button
and system power LED Green = System is on.
Amber = System is shut down, but power is still
applied.
Off = Power cord is not attached, power supply
failure has occurred, no power supplies are
installed, facility power is not available, or the
DC-to-DC converter is not installed.
Location Label 1 Label 2
In documentation, Command Line interface, and graphical
user interface Primary AUX
HP ProLiant EFS DL320-M25 WAN Accelerator Manager NIC1 NIC2
Item Description Status
