142 6 - D ISPLAYING AND C USTOMIZING HP EFS WAN A CCELERATOR M ANAGER R EPORTS
The Bandwidth Optimization report provides the following statistics that describe
bandwidth activity for the time period you specify.
What this Report
Tells You The Bandwidth Optimization report answers the following questions:
‹ How much bandwidth optimization has occurred?
‹ What was the average and peak amount of data sent?
‹ What was the rate at which data was sent?
‹ What was the overall increase in data transmitted?
To display the
Bandwidth
Optimization report 1. Click the Reports tab to display the Remote Appliances - Bandwidth Optimization
page.
Figure 6-1. Reports: Remote Appliances - Bandwidth Optimization Page
Field Description
WAN Data Specifies the Bytes sent over the Wide Area Network (WAN).
LAN Data Specifies the Bytes over the Local Area Network (LAN).
Total Data Reduction % over
Last Week Specifies the total decrease of data transmitted over the WAN.
Peak Data Reduction % over
Last Week Specifies the peak decrease in data transmitted over the WAN.
Peak Data Reduction Occurred
At Specifies the time that the peak data reduction occurred.
Capacity Increase Specifies the increase in the amount of data transmitted over the WAN.
