HP SN6000 Fibre Channel Switch QuickTools Switch Management User Guide

93

Auto Performance Tuning

Enables the switch to dynamically control the MFS_Enable, VI_Enable and

LCF_Enable features based on the operational state of the port.

AL Fairness

Controls how frequently the switch can arbitrate for access. Affects only

ports running in loop (FL) mode.

Port Binding

Ties a specific device WWN to a physical port number.

Upstream ISL

The ISL over which the switch sends requests intended for the principal

switch

Downstream ISL

The ISL over which the switch receives requests intended for the principal

switch.

Remote Switch WWN

Displays WWN, if known, of the isolated switch attempting a connection

on that port.

Extended Credits Group
Extended Credits Requested Number of credits requested by other ports
Max Credits Available

The maximum number of credits granted to a port that can be used when

extending port credits.

Credits to Donate

The number of credits available to be donated by the selected port.

Donor Group

The donor group of the selected port.

Valid Donor Groups

The number of separate groups within which extended credits may be

donated and assigned.

Media Group
Media Type

The transceiver fibre type, such as single mode, multi-mode, or copper.

Media Speed

The maximum transceiver speed

Media

The transceiver type.

Media Transmitter

The transceiver transmitter type, such as longwave, shortwave, or

electrical.

Media Distance

The maximum transceiver transmission distance

Media Vendor

The company that manufactured the SFP

Media Vendor ID

The IEEE registered company identification number

Media Part Number

The part number assigned to the SFP

Media Revision

Transceiver hardware version

Table 18

Port Information data window fields (Continued)

Field

Description
