66

Table 11

describes the network IP configuration parameters.

Table 11

Network Properties dialog box—IP fields

Field

Description

IPv4 Network

Enable this option to permit the IPv4 addressing format to be used anytime you

are required to enter an IP address.

CAUTION:

Disabling this option will prevent you from using an IPv4 IP

address for system services.

IPv6 Network

Enable this option to permit the IPv6 addressing format to be used anytime you

are required to enter an IP address.

CAUTION:

Disabling this option will prevent you from using an IPv6 IP

address for system services.

Network Discovery

Choose one of the following methods for assigning the IP address:

Static—Uses the IP configuration parameters entered in the Network

Properties dialog box.

BootP—Acquires the IP configuration from a BootP server. If no IP address is

obtained, the switch reverts to the previously configured IP address.

RARP (Reverse Address Resolution Protocol)—Acquires the IP address from a

RARP server. A RARP request is broadcast with up to three retries, each at 5

second intervals. If no IP address is obtained, the switch reverts to the

previously configured IP address.

DHCP (Dynamic Host Configuration Protocol)—Acquires the IP configuration

from a DHCP server. If no satisfactory lease is obtained, the DHCP client

attempts to use the previously configured lease. If the previous lease cannot

be used, no IP address will be assigned to this switch in order to avoid an IP

address conflict.

IP Address

Enter the Internet Protocol address for the Ethernet port. The default value is

10.0.0.1.

Subnet Mask

Enter the subnet mask address for the Ethernet port. The default value is

255.0.0.0.

Gateway

Enter the IPv4 gateway address

Discovery

Choose one of the following methods for assigning the IP address:

Static—Uses the IP configuration parameters entered in the Network

Properties dialog box

DHCPv6 (Dynamic Host Configuration Protocol version 6)—Acquires the IP

configuration from a DHCP server. If no satisfactory lease is obtained, the

DHCP client attempts to use the previously configured lease. If the previous

lease cannot be used, no IP address will be assigned to this switch in order

to avoid an IP address conflict.

NDP (Neighbor Discovery Protocol)—Part of the Stateless Address Auto

configuration protocol. It replaces the Address Resolution Protocol used with

IPv4.

Config IPv6 Address

Enter the IPv6 address for the Ethernet port

Gateway

Enter the IPv6 gateway address
