3.21 Installing the Database Server
System Reporter 2.8 3PAR System Reporter User’s Guide
As part of installing the System Reporter tools (see Installing or Upgrading the System Reporter
Tools on page 3.24), the installer creates two Apache HTTP Server config.tcl files to store
the user names and passwords for the cliuser and the webuser. See 7.8 Modifying the
Apache HTTP Server Configuration Files on page 7.23 for instructions on editing these
config.tcl files if you change the MySQL usernames and passwords at a later time.
4 Grant the two users the privilege levels described above by running the commands below:
use inservstats
grant all on * to cliuser;
grant select on * to webuser;
exit;
5 Exit the mysql command line by running the following command:
exit;
3.8.3 Setting Up the Oracle Database (Optional)
System Reporter supports the use of MySQL® Database Server or Oracle 11g Database Server.
To use Oracle, you must set up Oracle, following the instructions provided in this section. To
use and install MySQL go to 3.8.2 Installing and Setting Up the MySQL Database (Optional) on
page 3.16.
Oracle is optional third-party software and is not provided by 3PAR.
Installing the Oracle database server is beyond the scope of this guide. We assume that you
already have an Oracle database server. In this section we describe how to create a database
and users on that server for the System Reporter and how to set up a connection to the
database from the System Reporter.
3.8.3.1 Creating an Oracle database
On the Oracle database server:
1 Start the Oracle Database Configuration Assistant.
NOTE: When creating the users, you must assign them passwords in order for
System Reporter to function properly.
