Figure 48 Volume Information Panel
.
NOTE:
This example shows a Data Exchange volume definition file that defines only one Data Exchange
volume.
Mainframe File Information Dialog
The View-MF-file information… command displays the following information for the mainframe (MF)
files (datasets) in the volume specified in the Mainframe file field on the FCU main panel:
•
= the dataset can be processed by FCU.
= the dataset cannot be processed by FCU.
? = the dataset can be processed by FCU only if the VSE record option is used to specify the RF,
RL, and BL.
• Dataset = dataset name
• DO = dataset organization type: SAM, DAM, PAM, VSAM, ? (other than above)
• RF = record format: F (fixed-length), V (variable-length), U (undefined), S (spanned), ? (other than
above)
• BL = block length
• RL = record length
• DS = dataset size (in number of tracks)
Using the Data Exchange Software 90
