Command line 85
Item Description
Parameters
ConnectionId
(required)
The ID of an existing Ethernet connection associated with a profile and a server
port. The format of the ConnectionID is .
Properties
Uplinkset (required) The name of the shared uplink set to use with the server port mapping
VLANIDs (required) The VLAN IDs to use for the mapping. The format is a comma-separated list of VLAN
ID ranges, where a range is either a single VLAN ID or a hyphen-separated pair of
VLAN IDs that identify a range of VLAN IDs. Valid VLAN ID values include 1 to
4094.
MatchUplinkSet
(optional)
Requires that the VLANs used for mappings match the VLAN IDs specified on the
identified Uplink Set. If set to false, the command will not set the profile connection
associated uplink set attribute (but will use the uplink set VLAN IDs from the uplink
set). If there are already server port map entries for the specified profile connection,
then either the uplink set must match or the port map entries must not have the
associated uplink set attribute specified. The default value of this attribute is "false".
Examples
->add server-port-map-range MyProfile:1
UplinkSet=MyUplinkSet1 VLanIds=101-124,214
Adds multiple networks to a server-port-map
->add server-port-map-range MyProfile:2
UplinkSet=MyUplinkSet2 VLanIds=1-20 MatchUplinkSet=true
Adds multiple networks to a server-port-map and locks VLANs to an uplink set
Item Description
remove server-port-
map-range
Remove one or more server port network mappings.
Syntax
remove server-port-map-range VLANIds=
Range List>
Parameters
ConnectionId
(required)
The ID of an existing Ethernet connection associated with a profile and a server
port. The format of the Connection ID is .
VLANIDs (required) The list of VLAN IDs to be removed from the mapping. The format is a
comma-separated list of VLAN ID ranges, where a range is either a single VLAN ID
or a hyphen-separated pair of VLAN IDs that identify a range of VLAN IDs. Valid
VLAN ID values include 1 to 4094.
Example
->remove server-port-map-range MyProfile:1
VLanIds=151-170,215
Removes multiple server port network mappings
snmp
View and modify the SNMP configuration for VC-Enet and VC-FC modules, and add, modify, and remove
SNMP trap configurations related to trap destinations.
Supported actions: set, show, help
Item Description
set snmp Modify the VC SNMP configuration.
