Configuring the Virtual Connect domain using the CLI 155
remain in the "profile recovered" state until the server is powered down or removed from the enclosure. This
feature eliminates the power cycle requirement for a server to recover.
General requirements for adding FC or FCoE connections
Adding FC and FCoE connections is generally allowed during profile add and edit operations. It is not
allowed in some specific cases. Observe the following general requirements:
• When a profile is added, the FC/FCoE connections initially displayed are based on the FC/FCoE
module configuration in the domain. A pair of horizontally adjacent FC/FCoE-capable modules has
two connections.
• Connections can only be added or removed from the bottom. You can only add or delete connections
at the end of the list.
• You can remove connections at any time (one at a time, from the bottom).
• If the existing profile connections do not match the current FC/FCoE module configurations, the add
operation is not allowed.
• The current maximum number of per server profile FC/FCoE connections mapped to the same I/O bay
is four, unless you are using the HP Integrity BL890c i4 Server Blade.
o When FlexFabric modules exist in I/O bays 1 and 2, there can be an additional eight FCoE
connections that will get mapped to LOMs 3 and 4 on the blades in an Integrity BL890c i4 server.
The BL890c i4 server has CNA LOMs, which enable two FCoE connections to I/O bay 1 (from
LOMs 1 and 3) and two FCoE connections to I/O bay 2 (from LOMs 2 and 4).
The following table lists several scenarios that describe how adding FC/FCoE connections affects an existing
profile. The scenarios are true for FC module configurations and FC modules, as well as FCoE module
configurations and FCoE-capable modules.
Scenario Description Existing profile
connections Current FC module
configurations Adding profile connections
1 Start with modules in Bays 3
and 4, create a profile, then
edit the profile and add
connections.
Port Connected to
1 Bay 3
2 Bay 4
— —
Bay 3 Bay 4
—
—
— —
Port Connected to
1 Bay 3
2 Bay 4
3 Bay 3
4 Bay 4
Add connection, 2 times
2 Start with modules in Bays
3–6, create a profile, then
edit the profile and add
connections.
Port Connected to
1 Bay 3
2 Bay 4
3 Bay 5
4 Bay 6
— —
Bay 3 Bay 4
Bay 5 Bay 6
—
—
Port Connected to
1 Bay 3
2 Bay 4
3 Bay 5
4 Bay 6
5 Bay 3
6 Bay 4
7 Bay 5
8 Bay 6
Add connection, 4 times
3 Start with modules in Bays 3
and 4, create a profile,
install modules into Bays 5
and 6, then edit the profile
and add connections.
Port Connected to
1 Bay 3
2 Bay 4
— —
Bay 3 Bay 4
Bay 5 Bay 6
—
—
Port Connected to
1 Bay 3
2 Bay 4
3 Bay 5
4 Bay 6
Add connection, 2 times
