Command line 35
Item Description
Ports (required) A list of one or more logical FC ports to be added to the fabric. Each port is specified
in the format ",,...", where port is the interconnect module port number
to be added to the fabric, for example "1, 2, 3, 4" (affects all modules within a bay
group).
For HP VC FlexFabric 10Gb/24-port Modules, port numbers 1, 2, 3, and 4
correspond to ports X1, X2, X3, and X4, respectively.
Type (optional) The fabric type. "FabricAttach" is for a SAN fabric. A "DirectAttach" fabric is directly
connected to a supported storage device. A "DirectAttach" fabric is only allowed for a
FlexFabric module. The default type is "FabricAttach".
Speed (optional) The port speed for the uplink ports in the fabric. Valid values include "Auto", "2Gb",
"4Gb", and "8Gb". The default port speed is "Auto".
Speed restrictions:
• For the HP Virtual Connect 4Gb FC Module, if the value 8Gb is chosen, VCM
translates the value to "Auto", which allows the module to connect to the SAN
switch at optimal speed.
• For the HP VC 8Gb 24-Port FC Module, HP VC 8Gb 20-Port FC Module, and HP
VC FlexFabric 10Gb/24-port Module, valid speed values include "Auto", "2Gb",
"4Gb", and "8Gb".
LinkDist
(optional)
Specifies the login re-distribution scheme to use for load balancing. Valid values
include "Auto" and "Manual". The default login re-distribution is "Manual" for a
"FabricAttach" fabric. Login re-distribution is not supported for "DirectAttach" fabrics.
The HP 4Gb VC-FC Module, HP Virtual Connect 4Gb FC Module, HP VC 8Gb 20-Port
FC Module, and HP VC 8Gb 24-Port Module support only manual login redistribution.
The HP VC FlexFabric 10Gb/24-port Module supports both auto and manual login
redistribution.
Examples
->add fabric MyFabric1 Bay=3 Ports=1,2
Adds a new FabricAttach fabric, using default values
->add fabric MyFabric5 Bay=3 Ports=1,2 Type=DirectAttach
Adds a new DirectAttach fabric
->add fabric MyFabric2 Bay=3 Ports=1 Speed=2Gb
Adds a new fabric with speed set to 2Gb
->add fabric MyFabric3 Bay=3 Ports=1,2,3,4 LinkDist=Auto
Adds a new fabric with automatic login re-distribution
->add fabric MyFabric4 Bay=3 Ports=1,2
Adds a new fabric with two logical ports
Item Description
remove fabric Remove an existing fabric from the domain.
Syntax
remove fabric
Parameter
Name (required) The name of a specific fabric. Use "*" to remove all existing fabrics.
Examples
->remove fabric VFabric_1
Removes VC FC SAN fabric VFabric_1
->remove fabric *
Removes all VC FC SAN fabrics from the domain
Item Description
set fabric Modify properties of an existing fabric. This command can also be used to force load
