Configuring the Virtual Connect domain using the CLI 157
9 Start with FCoE-capable
modules in Bays 1 and 2,
then create a profile and
add connections.
Port Connected to
1 Bay 1
2 Bay 2
Bay 1 Bay 2
— —
— —
— —
Port Connected to
1 Bay 1
2 Bay 2
3 Bay 1
4 Bay 2
5 Bay 1
6 Bay 2
7 Bay 1
8 Bay 2
Add connection, 6 times*
10 Start with 8 FCoE-capable
modules, then create a
profile and add connections.
Port Connected to
1 Bay 1
2 Bay 2
3 Bay 3
4 Bay 4
5 Bay 5
6 Bay 6
7 Bay 7
8 Bay 8
Bay 1 Bay 2
Bay 3 Bay 4
Bay 5 Bay 6
Bay 7 Bay 8
Port Connected to
1 Bay 1
2 Bay 2
3 Bay 3
4 Bay 4
5 Bay 5
6 Bay 6
7 Bay 7
8 Bay 8
9 Bay 1
10 Bay 2
11 Bay 3
12 Bay 4
13 Bay 5
14 Bay 6
15 Bay 7
16 Bay 8
17 Bay 1
18 Bay 2
19 Bay 3**
20 Bay 4**
21 Bay 5**
22 Bay 6**
23 Bay 7**
24 Bay 8**
25 Bay 1
26 Bay 2
Add connection, 18 times
* Using the BL890c i4 server blade, an additional eight connections can still be added. Each pair is connect to bays 1
and 2. The first four pairs of entries are mapped to LOM 1 and LOM 2 on each blade, and the last four pairs of entries
are mapped to LOM 3 and LOM 4 on each blade.
** Not mapped
Logging out of the CLI
To log out of the CLI, use the exit command:
>exit
Common management operations
The following table provides the syntax for the most commonly used management operations.
For more information on a particular command, see "Managed elements (on page
17 )."
