EasiCool™
Precision Air Conditioning
88
EasiCool Technical Manual 7535776 V1.1.0_04_2013
Te
ch
ni
ca
l
DF
380
V
6
0H
z
W
X - T
yp
e
DF50WX2-EZRE-1
DF55WX2-EZRE-1
DF60WX2-EZRE-1
Capacity
(1)
Nominal Cooling
kW
52.7
60.6
68.5
Total Heat of Rejection
kW
70.6
81.7
92.4
Capacity Steps
2
2
2
Dimensions - W x D x H
mm
2170 x 750 x 1940
2170x 750 x 1940
2170x 750 x 1940
Weight
(3)
kg
712 / 722
731 / 741
731 / 741
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour
Frame: Aluminium Frame With Aluminium Corners
Evaporator
Rifled Copper Tube / Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages
2/1
2/1
2/1
Condenser
Stainless Steel Brazed Plate
Water Volume
l
9.9
9.9
9.9
Evaporator Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed To 25Pa ESP
Fan Transmission Type
Belt & Pulley
Quantity
2
2
2
Motor Shaft Power
(4)
kW
2.2
2.2
3
Speed @ 25Pa / Maximum ESP
rpm
1167 / 1170
1167 / 1170
1307 / 1311
Maximum ESP
Pa
35
35
75
Nominal Airflow
m³/s
4.20
4.20
4.60
Compressor - Scroll
Tandem
Quantity
2
2
2
Oil Charge Volume (Total)
l
6.60
6.60
6.60
Oil Type
Polyol Ester
Refrigeration
(5)
Single Circuit
Refrigeration Control & Type
Thermostatic Expansion Valve (Optional EEV) / R410A
Charge (Total)
kg
9.0
9.7
9.8
Connections
Water Inlet / Outlet
mm
42
42
42
Condensate Drain Hose
mm
19
19
19
Filtration
Disposable To BS EN 779 - G4 - 75mm
Quantity
4
4
4
OPTIONAL EXTRAS
Electric Heating (Total)
kW
30.0
30.0
30.0
Humidifier
Capacity
kg/hr
3.0 - 15.0
3.0 - 15.0
3.0 - 15.0
Feed/Drain
3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Condensate Pump
Head
m
5
5
5
Flow
l/m
10.8
10.8
10.8
Drain
10mm Stainless Steel Stub Connection
Evaporator Fan Options:
Optional Fan - EC Motor
Centrifugal Backward Curved EC - Designed To 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
2
2
2
Motor Shaft Power
(4)
kW
N/A
N/A
N/A
Speed @ 25Pa / Maximum ESP
rpm
1265 / 1510
1265 / 1510
1390 / 1510
Maximum ESP
Pa
320
320
185
Low Pressure Hot Water
(7)
Copper Tube / Aluminium Fin
Capacity Gross
kW
30.00
31.50
31.50
Water Flow (Nominal)
l/s
1
1
1
LPHW Connection Sizes
mm
22
22
22
Threaded Connection
Brass Male Taper
in
1 1/4
1 1/4
1 1/2
Technical Data Downflow Units WX Type
Mechanical Data
DF50WX2 - DF60WX2
