EasiCool™ Precision Air Conditioning
146 EasiCool Technical Manual 7535776 V1.1.0_04_2013
Te
ch
ni
ca
l
DF
22
0V
6
0H
z
W
X - T
yp
e
DF8WX-EZRE-2 DF10WX-EZRE-2
Capacity (1)
Nominal Cooling kW 9.6 10.6
Total Heat of Rejection kW 12.8 14.1
Capacity Steps 1 1
Dimensions - W x D x H mm 670 x 670 x 1940 670 x 670 x 1940
Weight (3) kg 218 / 219 240 / 241
Construction Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour Frame: Aluminium Frame With Aluminium Corners
Evaporator Rifled Copper Tube / Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages 1/1 1/1
Condenser Stainless Steel Brazed Plate
Water Volume l 1.4 1.4
Evaporator Fan Motor - AC Motor Centrifugal Forward Curved AC - Designed To 25Pa ESP
Fan Transmission Type Direct Drive
Quantity 1 1
Motor Shaft Power (4) kW N/A N/A
Maximum ESP Pa 140 118
Nominal Airflow m³/s 0.75 0.95
Compressor - Scroll Single
Quantity 1 1
Oil Charge Volume (Total) l 0.70 1.20
Oil Type Polyol Ester
Connections
Water Inlet / Outlet
mm 22 22
Condensate Drain Hose mm 19 19
Filtration Disposable To BS EN 779 - G4 - 50mm
Quantity 1 1
OPTIONAL EXTRAS
Electric Heating (Total)
kW 7.5 7.5
Humidifier
Capacity
kg/hr 0.6 - 3.0 0.6 - 3.0
Feed/Drain 3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Condensate Pump
Head
m 8 8
Flow l/m 5 5
Drain 10mm Stainless Steel Stub Connection
Optional Fan - EC Motor Centrifugal Backward Curved EC - Designed To 25Pa ESP
Fan Transmission Type Direct Drive
Quantity 1 1
Motor Shaft Power (4) kW N/A N/A
Speed @ 25Pa / Maximum ESP rpm 1705 / 2215 2145 / 2215
Maximum ESP Pa 295 50
Low Pressure Hot Water (7) Copper Tube / Aluminium Fin
Capacity Gross kW 7.5 8.4
Water Flow (Nominal) l/s 0.17 0.19
LPHW Connection Sizes mm 22 22
Threaded Connection
Brass Male Taper
in 3/4 3/4
Technical Data Downflow Units WX Type
Mechanical Data
DF8WX - DF10WX
