EasiCool™ Precision Air Conditioning
System Configuration
Downflow Upflow
X Type WX Type X Type WX Type
EC Forward Curve Direct Drive Fans 8 - 26
○ ○ ○ ○
Airflow Components
AC Forward Curved Direct Drive Fans 8 - 26
● ● ● ●
AC Forward Cureved Belt and Pulley Fans 28 - 60
● ● ● ●
EC Backward Curved Direct Drive Fans 28 - 60
○ ○ ○ ○
AC Larger Fan Motor**
○ ○ ○ ○
2 way Discharge Grille
– – ○ ○
3 Way Discharge Grille
– – ○ ○
Return Air Grille
– – ● ●
G4 Return Door Air Filter
○ ○ ○ ○
High efficiency Filtration with pre-filter G3+F6
○ ○ ○ ○
Open Floorstand
○ ○ ○ ○
Enclosed Floorstand
○ ○ ○ ○
●
Standard Feature
○
Optional Feature
–
Not Available
**
Model Dependant.
Airflow Components
EC Direct Drive Forward
Curved Fan EC Direct Drive Backward
Curved Fan Pleated Disposable Panel Filter
