EasiCool™ Precision Air Conditioning
Unit Refrigerant Charge
(kg / Circuit)
44 EasiCool Technical Manual 7535776 V1.1.0_04_2013
Ins
ta
lla
tio
n
IMPORTANT
The pipe sizes/refrigerant charges quoted are for guidance only. It is the responsibility of the installing contractor/site
engineer to check the pipe sizes/refrigerant charges are correct for each system installation and application.
Split systems may require additional oil which should be added to the low side of each compressor.
Design should be in accordance with accepted refrigeration practice to ensure good oil return to the compressor(s)
under all normal operating conditions.
Indoor Unit Standard Condenser Larger Condenser
(IR) kg/Circuit
HGRH (1)
(OR) kg/Circuit (OR) kg/Circuit kg/Circuit
V8X-EZRE 1 1.1 CR16 2.7 CR22 2.2
V10X-EZRE 1 1.1 CR16 2.7 CR22 2.2
V13X-EZRE 1.5 1.7 CR22 2.2 CR30 4.3
V15X-EZRE 1.5 1.7 CR22 2.2 CR30 4.3
V17X-EZRE 1.5 1.7 CR30 4.3 CR50 4.9
V20X2-EZRE 2.2 2.5 CR30 4.3 CR50 4.9
V22X2-EZRE 2.2 2.5 CR50 4.9 CR65 9.8
V26X2-EZRE 2.2 2.5 CR50 4.9 CR65 9.8
V28X-EZRE 2.7 3 CR50 4.9 CR65 9.8
V28X2-EZRE 2.6 2.9 CR50 4.9 CR65 9.8
V31X-EZRE 2.7 3 CR50 4.9 CR65 9.8
V31X2-EZRE 2.6 2.9 CR50 4.9 CR65 9.8
V35X-EZRE 3.3 3.7 CR50 4.9 CR65 9.8
V35X2-EZRE 3.3 3.7 CR50 4.9 CR65 9.8
V40X-EZRE 3.5 4 CR65 9.8 CR80 8.4
V40X2-EZRE 3.6 4.1 CR65 9.8 CR80 8.4
V45X2-EZRE 4.2 4.7 CR80 8.4 CR105 16.7
V50X2-EZRE 4.5 5.1 CR80 8.4 CR105 16.7
V55X2-EZRE 5.2 5.8 CR80 8.4 CR105 16.7
V60X2-EZRE 5.4 5.9 CR80 8.4 CR105 16.7
