EasiCool™
Precision Air Conditioning
132
EasiCool Technical Manual 7535776 V1.1.0_04_2013
Te
ch
ni
ca
l
X-
Ty
pe
22
0V
6
0H
z
V
V20X2-EZRE-2
V22X2-EZRE-2
V26X2-EZRE-2
Standard Condenser Match
CR30
CR50
CR50
Capacity
Nominal Cooling
(1)
kW
23.4
25.1
27.0
Capacity Steps
2
2
2
Dimensions - W x D x H
mm
1310 x 670 x 1940
1310 x 670 x 1940
1310 x 670 x 1940
Weight
(3)
kg
289
289
289
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour
Frame: Aluminium Frame With Aluminium Corners
Evaporator
Rifled Copper Tube / Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages
2/1
2/1
2/1
Evaporator Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed To 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
2
2
2
Motor Shaft Power
(4)
kW
N/A
N/A
N/A
Maximum ESP
Pa
203
55
55
Nominal Airflow
m³/s
1.70
2.00
2.00
Compressor - Scroll
Tandem
Quantity
2
2
2
Oil Charge Volume (Total)
l
2.40
2.40
2.40
Oil Type
Polyol Ester
Refrigeration
(5)
Single Circuit
Refrigeration Control & Type
Thermostatic Expansion Valve (Optional EEV) / R410A
Holding Charge
Inert Gas
Connections
Liquid (Sweat)
in
1/2
1/2
1/2
Discharge (Sweat)
in
7/8
7/8
7/8
Filtration
Disposable To BS EN 779 - G4 - 50mm
Quantity
3
3
3
OPTIONAL EXTRAS
Larger Condenser Match
CR50
CR65
CR65
Nominal Cooling
kW
24.4
25.1
27.0
Hot Gas Reheat
(6)
Nom Heating (Gross)
kW
11.8
12.7
12.7
Electric Heating (Total)
kW
15.0
15.0
15.0
Humidifier
Capacity
kg/hr
0.6 - 3.0
0.6 - 3.0
0.6 - 3.0
Feed/Drain
3/4” BSPF Braided Flexible Hose / 19 mm Hose Connection
Condensate Pump
Head
m
8
8
8
Flow
l/m
5
5
5
Drain
10mm Stainless Steel Stub Connection
Optional Fan - EC Motor
Centrifugal Backward Curved EC - Designed To 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
1
1
1
Motor Shaft Power
(4)
kW
N/A
N/A
N/A
Speed @ 25Pa / Maximum ESP
rpm
1830 / 2165
2165 / 2165
2165 / 2165
Maximum ESP
Pa
285
25
25
Low Pressure Hot Water
(7)
Copper Tube / Aluminium Fin
Capacity Gross
kW
19.2
19.9
19.9
Water Flow (Nominal)
l/s
0.43
0.44
0.44
LPHW Connection Sizes
mm
22
22
22
Technical Data Downflow Units X Type
Mechanical Data
V20X2 - V26X2
