EasiCool™ Precision Air Conditioning
General Features
Open & Enclosed Floorstand
Open or enclosed floorstands are available, complete with adjustable feet and floor tile lip. Enclosed floorstands
incorporate an air turning vane. Height of the floorstand; please specify at order.
Discharge Air Configuration
Standard configuration is forward air discharge. Reverse air discharge is available, please specify at order.
Ceiling Duct Extension
Straight and ‘L’ shaped duct extensions up to a height of 1350 mm constructed and finished to match the unit are
available.
For extensions greater than 1350 mm, please contact Airedale.
Height; please specify at order.
Services Side Access Gland Plate
As standard services can be routed through the gland plate in the base of the units. A gland plate can be optionally
located to the lower left hand side face of the unit, if required.
Plain Doors - No Display Keypad
Networking is a standard option of the AireTronix microprocessor; refer to Controls, for full details. To reduce costs, the
“slave” units can be supplied with plain doors (no display keypad), in all door types, please specify at order.
Threaded Water Pipe Connection
As an alternative to brazed water pipe connections, BSP brass male taper threaded connections can be factory fitted.
Sterling Board LAT (Wooden Case) Packing
Units shall be supplied complete with additional LAT corner protection and cross braces to afford extra transit protection.
Sterling board heat treated man made material shall be used (including pallet) to comply with phytosanity import
regulations (please contact Airedale for this option).
System Configuration
Downflow Upflow
X Type WX Type X Type WX Type
Secure Door Locks
● ● ● ●
Return Air Grille
– – ● ●
Cold Water Condensate Pump
○ ○ ○ ○
Open Floorstand
○ ○ ○ ○
Enclosed Floorstand
○ ○ ○ ○
Ceiling Duct Extension
○ ○ ○ ○
●
Standard Feature
○
Optional Feature
–
Not Available
29 EasiCool Technical Manual 7535776 V1.1.0_04_2013
