EasiCool™
Precision Air Conditioning
140
EasiCool Technical Manual 7535776 V1.1.0_04_2013
Te
ch
ni
ca
l
X-
Ty
pe
22
0V
6
0H
z
V
V50X2-EZRE-2
V55X2-EZRE-2
V60X2-EZRE-2
Standard Condenser Match
CR80
CR80
CR80
Capacity
Nominal Cooling
(1)
kW
53.0
60.1
67.1
Capacity Steps
2
2
2
Dimensions - W x D x H
mm
2170 x 750 x 1940
2170 x 750 x 1940
2170 x 750 x 1940
Weight
(3)
kg
619
636
640
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour
Frame: Aluminium Frame With Aluminium Corners
Evaporator
Rifled Copper Tube / Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages
2/1
2/1
2/1
Evaporator Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed To 25Pa ESP
Fan Transmission Type
Belt & Pulley
Quantity
2
2
2
Motor Shaft Power
(4)
kW
3.0
3.0
3.0
Speed @ 25Pa / Maximum ESP
rpm
1243 / 1447
1243 / 1447
1278 / 1324
Maximum ESP
Pa
255
255
35
Nominal Airflow
m³/s
4.20
4.20
4.60
Compressor - Scroll
Tandem
Quantity
2
2
2
Oil Charge Volume (Total)
l
6.60
6.60
6.60
Oil Type
Polyol Ester
Refrigeration
(5)
Single Circuit
Refrigeration Control & Type
Thermostatic Expansion Valve (Optional EEV) / R410A
Holding Charge
Inert Gas
Connections
Liquid (Sweat)
in
5/8
5/8
5/8
Discharge (Sweat)
in
1 3/8
1 3/8
1 3/8
Filtration
Disposable To BS EN 779 - G4 - 75mm
Quantity
5
5
5
OPTIONAL EXTRAS
Larger Condenser Match
CR105
CR105
CR105
Nominal Cooling
kW
53.6
61.2
68.6
Hot Gas Reheat
(6)
Nom Heating (Gross)
kW
25.7
25.7
26.7
Electric Heating (Total)
kW
30.0
30.0
30
Humidifier
Capacity
kg/hr
3.0 - 15.0
3.0 - 15.0
3.0 - 15.0
Feed/Drain
3/4” BSPF Braided Flexible Hose / 19 mm Hose Connection
Condensate Pump
Head
m
5
5
5
Flow
l/m
10.8
10.8
10.8
Drain
10mm Stainless Steel Stub Connection
Evaporator Fan Options:
Larger Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed To 25Pa ESP
Fan Transmission Type
Belt & Pulley
Quantity
(4)
kW
2
2
2
Motor Shaft Power
kW
4.0
4.0
4.0
Speed @ Maximum ESP
rpm
1495
1495
1499
Maximum ESP
Pa
305
305
230
Optional Fan - EC Motor
Centrifugal Backward Curved EC - Designed to 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
2
2
2
Motor Shaft Power
(4)
kW
N/A
N/A
N/A
Speed @ 25Pa / Maximum ESP
rpm
1370 / 1510
1370 / 1510
1510 / 1510
Maximum ESP
Pa
165
165
25
Low Pressure Hot Water
(7)
Copper Tube / Aluminium Fin
Capacity Gross
kW
37.7
37.7
39.2
Water Flow (Nominal)
l/s
0.84
0.84
0.87
LPHW Connection Sizes
mm
22
22
22
Technical Data Downflow Units X Type
Mechanical Data
V50X2 - V60X2
