Page 86: Mechanical data df35wx - df45wx
EasiCool™
Precision Air Conditioning
86
EasiCool Technical Manual 7535776 V1.1.0_04_2013
Te
ch
ni
ca
l
DF
380
V
6
0H
z
W
X - T
yp
e
DF35WX-EZRE-1
DF40WX-EZRE-1
DF45WX-EZRE-1
Capacity
(1)
Nominal Cooling
kW
36.7
41.5
46.3
Total Heat of Rejection
kW
48.8
55.3
61.6
Capacity Steps
1
1
1
Dimensions - W x D x H
mm
1835 x 750 x 1940
1835x 750 x 1940
1835 x 750 x 1940
Weight
(3)
kg
537 / 543
565 / 571
640 / 650
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour
Frame: Aluminium Frame With Aluminium Corners
Evaporator
Rifled Copper Tube / Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages
1/1
1/1
1/1
Condenser
Stainless Steel Brazed Plate
Water Volume
l
6.1
6.1
9.9
Evaporator Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed To 25Pa ESP
Fan Transmission Type
Belt & Pulley
Quantity
1
1
1
Motor Shaft Power
(4)
kW
4
5.5
5.5
Speed @ 25Pa / Maximum ESP
rpm
980 /1078
1094 / 1186
1094 / 1186
Maximum ESP
Pa
165
175
175
Nominal Airflow
m³/s
3.30
3.70
3.70
Compressor - Scroll
Single
Quantity
1
1
1
Oil Charge Volume (Total)
l
3.30
3.30
6.70
Oil Type
Polyol Ester
Refrigeration
(5)
Single Circuit
Refrigeration Control & Type
Thermostatic Expansion Valve (Optional EEV) / R410A
Charge (Total)
kg
6.0
6.0
8.7
Connections
Water Inlet / Outlet
mm
35
35
42
Condensate Drain Hose
mm
19
19
19
Filtration
Disposable To BS EN 779 - G4 - 75mm
Quantity
3
3
3
OPTIONAL EXTRAS
Electric Heating (Total)
kW
20.0
20.0
20.0
Humidifier
Capacity
kg/hr
3.0 - 15.0
3.0 - 15.0
3.0 - 15.0
Feed/Drain
3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Condensate Pump
Head
m
5
5
5
Flow
l/m
10.8
10.8
10.8
Drain
10mm Stainless Steel Stub Connection
Evaporator Fan Options:
Larger Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed To 25Pa ESP
Fan Transmission Type
Belt & Pulley
N/A
N/A
Quantity
1
N/A
N/A
Motor Shaft Power
(4)
kW
5.5
N/A
N/A
Speed @ Maximum ESP
rpm
1196
N/A
N/A
Maximum ESP
Pa
322
N/A
N/A
Optional Fan - EC Motor
Centrifugal Backward Curved DD EC - Designed To 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
2
2
2
Motor Shaft Power
(4)
kW
N/A
N/A
N/A
Speed @ 25Pa / Maximum ESP
rpm
1895 / 2165
2135 / 2165
2135 / 2165
Maximum ESP
Pa
285
70
70
Low Pressure Hot Water
(7)
Copper Tube / Aluminium Fin
Capacity Gross
kW
30.0
31.5
31.5
Water Flow (Nominal)
l/s
0.67
0.70
0.70
LPHW Connection Sizes
mm
22
22
22
Threaded Connection
Brass Male Taper
in
1 1/4
1 1/4
1 1/2
Technical Data Downflow Units WX Type
Mechanical Data
DF35WX - DF45WX
