EasiCool™ Precision Air Conditioning
136 EasiCool Technical Manual 7535776 V1.1.0_04_2013
Te
ch
ni
ca
l
X-
Ty
pe
22
0V
6
0H
z
V
V35X-EZRE-2 V35X2-EZRE-2
Standard Condenser Match CR50 CR50
Capacity
Nominal Cooling
(1) kW 36.5 38.4
Capacity Steps 1 2
Dimensions - W x D x H mm 1835 x 750 x 1940 1835 x 750 x 1940
Weight (3) kg 474 516
Construction Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour Frame: Aluminium Frame With Aluminium Corners
Evaporator Rifled Copper Tube / Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages 1/1 2/1
Evaporator Fan Motor - AC Motor Centrifugal Forward Curved AC - Designed To 25Pa ESP
Fan Transmission Type Belt & Pulley
Quantity 1 1
Motor Shaft Power (4) kW 4 4
Speed @ 25Pa / Maximum ESP rpm 1440 / 1468 1440 / 1468
Maximum ESP Pa 35 35
Nominal Airflow m³/s 3 3
Compressor - Scroll Single Tandem
Quantity 1 2
Oil Charge Volume (Total) l 3.30 3.32
Oil Type Polyol Ester
Refrigeration (5) Single Circuit
Refrigeration Control & Type Thermostatic Expansion Valve (Optional EEV) / R410A
Holding Charge Inert Gas
Connections
Liquid (Sweat)
in 1/2 1/2
Discharge (Sweat) in 7/8 7/8
Filtration Disposable To BS EN 779 - G4 - 75mm
Quantity 4 4
OPTIONAL EXTRAS
Larger Condenser Match
CR65 CR65
Nominal Cooling kW 37.3 39.4
Hot Gas Reheat (6)
Nom Heating (Gross) kW 19.4 19.4
Electric Heating (Total) kW 30.0 30.0
Humidifier
Capacity
kg/hr 3.0 - 15.0 3.0 - 15.0
Feed/Drain 3/4” BSPF Braided Flexible Hose / 19 mm Hose Connection
Condensate Pump
Head
m 5 5
Flow l/m 10.8 10.8
Drain 10mm Stainless Steel Stub Connection
Evaporator Fan Options:
Larger Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed To 25Pa ESP
Fan Transmission Type Belt & Pulley
Quantity (4) kW 1 1
Motor Shaft Power kW 5.5 5.5
Speed @ Maximum ESP rpm 1695 1695
Maximum ESP Pa 240 240
Optional Fan - EC Motor Centrifugal Backward Curved EC - Designed to 25Pa ESP
Fan Transmission Type Direct Drive
Quantity 2 2
Motor Shaft Power (4) kW N/A N/A
Speed @ 25Pa / Maximum ESP rpm 1935 / 2165 1935 / 2165
Maximum ESP Pa 260 260
Low Pressure Hot Water (7) Copper Tube / Aluminium Fin
Capacity Gross kW 29.9 29.9
Water Flow (Nominal) l/s 0.67 0.67
LPHW Connection Sizes mm 22 22
Technical Data Downflow Units X Type
Mechanical Data
V35X - V35X2
