EasiCool™ Precision Air Conditioning
Dimensional & Installation Data
Positioning
Down flow
IMPORTANT
When placing the unit on the floorstand ensure appropriate air seal is used to prevent leakage at the join.
It is also important to place all locking bolts in place to secure the unit to its base (EC fan floorstands only).
Standard Return and Optional Backward Curved EC Fan Motors Standard Return and Standard Fan Motors
37 EasiCool Technical Manual 7535776 V1.1.0_04_2013
Ins
ta
lla
tio
n
(1) With adjustable feet fitted
(2) With variable size leg and adjustable feet fitted
