EasiCool™
Precision Air Conditioning
61
EasiCool Technical Manual 7535776 V1.1.0_04_2013
Te
ch
nic
al
X-T
yp
e
DF
380
V
6
0H
z
DF35X-EZRE-1
DF40X-EZRE-1
DF45X-EZRE-1
Standard Condenser Match
CR50
CR65
CR80
Unit Data Full Function
(1)
Nominal Run Amps
A
74.0
84.1
89.9
Maximum Start Amps
A
226.1
236.5
255.5
Recommended Mains Fuse Size
A
100
100
100
Unit Data Cooling Only
(2)
Nominal Run Amps
A
39.8
50.0
55.7
Maximum Start Amps
A
191.9
202.3
221.4
Recommended Mains Fuse Size
A
50
63
80
Max Mains Incoming Cable Size
mm²
35
35
35
Mains Supply
V
380V / 3PH + N / 60HZ
Control Circuit
VAC
24
24
24
Evaporator Fan - Motor Per Fan
Centrifugal Forward Curved DD EC - Designed to 25Pa ESP
Electrical Input Power
(3)
kW
4.6
6.3
6.3
Full Load Amps
A
8.34
14.8
14.8
Locked Rotor Amps
A
58
114
114
Compressor - Per Compressor
Quantity x Motor Size
kW
1 x 13.98
1 x 16.07
1 x 18.09
Nominal Run Amps
A
24.93
28.62
31.4
Locked Rotor Amps
A
177
181
197
Type of Start
Direct On Line
Standard Condenser Match - AC Motor - Per Fan
Electrical Input Power
kW
0.64
0.64
0.64
Full Load Amps
A
3.02
3.02
3.02
OPTIONAL EXTRAS
Electric Heating
Stage of Reheat
3
3
3
Number of Elements
8
8
8
Rating
kW
20
20
20
Current Per Phase
A
34.19
34.19
34.19
Humidifier
Capacity
kg/hr
15
15
15
Rating
kW
11.25
11.25
11.25
Full Load Amps
A
17.1
17.1
17.1
Evaporator Fan Options
Larger Fan Motor - AC Motor - Per Fan
Centrifugal Forward Curved AC - Designed to 25Pa ESP
Electrical Input Power
(3)
kW
6.3
N/A
N/A
Full Load Amps
A
11.5
N/A
N/A
Locked Rotor Amps
A
114
N/A
N/A
Standard Size Motor - EC Motor - Per Fan
Centrifugal Backward Curved DD EC - Designed to 25Pa ESP
Electrical Input Power
(3)
kW
2.55
2.55
2.55
Full Load Amps
A
3.9
3.9
3.9
Condenser Fan Options
Standard Condenser Motor - EC Motor - Per Fan
Electrical Input Power
kW
0.73
0.73
0.73
Full Load Amps
A
3.3
3.3
3.3
Technical Data Downflow Units X Type
Electrical Data
Mechanical
(1)
Entering air 24°C/45% RH ambient 35°C.
(2)
Fan Gain / Fan power input based upon fan operating with design airflow at 25Pa ESP, These values may change with different ESP.
(3)
With Standard forward curved fan motors; Machine weight includes a refrigerant charge.
(4)
Backward curved EC fan options quote electrical power. All other options quote shaft power.
(5)
For refrigerant charges, refer to
Unit Refrigerant Charge (kg/Circuit)
.
(6)
Based on air temperature of 15.5°C leaving the evaporator coil.
(7)
Based upon low pressure hot water 82°C inlet / 71°C outlet. Air on 20°C. Refer to
Low Pressure Hot Water
.
Electrical
(1)
Values given for full function units (incl. electric heating, humidification and matched condenser) at 7°C evaporating and 54.4°C condensing with standard
forward curved fan motors, for optional data, please contact Airedale.
(2)
Values given for Cooling only units (incl. Compressor, evaporator fan and matched condenser) at 7°C evaporating and 54.4°C condensing, for optional
data, please contact Airedale.
(3)
Electrical input power relates to the maximum absorbed electrical power. Actual operating fan power input is shown in the mechanical data tables.
