Page 62: Mechanical data df35x - df45x
EasiCool™
Precision Air Conditioning
62
EasiCool Technical Manual 7535776 V1.1.0_04_2013
Te
ch
ni
ca
l
X-
Ty
pe
DF
380
V
6
0H
z
DF35X-EZRE-1
DF40X-EZRE-1
DF45X-EZRE-1
Standard Condenser Match
CR50
CR65
CR80
Capacity
(1)
Nominal Cooling
kW
35.9
41.1
46.3
Capacity Steps
1
1
1
Dimensions - W x D x H
mm
1835 x 750 x 1940
1835 x 750 x 1940
1835 x 750 x 1940
Weight
(3)
kg
477
500
553
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour
Frame: Aluminium Frame With Aluminium Corners
Evaporator
Rifled Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages
1/1
1/1
1/1
Evaporator Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed to 25Pa ESP
Fan Transmission Type
Belt & Pulley
Quantity
kW
1
1
1
Motor Shaft Power
(4)
kW
4.0
5.5
5.5
Speed @ 25Pa / Maximum ESP
rpm
980 /1078
1094 / 1186
1094 / 1186
Maximum ESP
Pa
165
175
175
Nominal Airflow
m³/s
3.30
3.70
3.70
Compressor - Scroll
Single
Quantity
1
1
1
Oil Charge Volume (Total)
l
3.30
3.30
6.70
Oil Type
Polyol Ester
Refrigeration
(5)
Single Circuit
Refrigeration Control & Type
Thermostatic Expansion Valve (Optional EEV) / R410A
Holding Charge
Inert Gas
Connections
Liquid (Sweat)
in
1/2
5/8
5/8
Discharge (Sweat)
in
7/8
1 1/8
1 1/8
Condensate Drain Hose
mm
19
19
19
Filtration
Disposable To BS EN 779 - G4 - 50mm
Quantity
3
3
3
OPTIONAL EXTRAS
Larger Condenser Match
CR65
CR80
CR105
Nom Cooling (Gross)
kW
36.7
41.5
46.3
Hot Gas Reheat
(6)
Nominal Heating
kW
19.4
20.3
20.3
Electric Heating (Total)
kW
20.0
20.0
20.0
Humidifier
Capacity
kg/hr
3.0 - 15.0
3.0 - 15.0
3.0 - 15.0
Feed/Drain
3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Condensate Pump
Head
m
8
8
5.0
Flow
l/m
5
5
10.8
Drain
10mm Stainless Steel Stub Connection
Evaporator Fan Options:
Larger Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed to 25Pa ESP
Fan Transmission Type
Belt & Pulley
Quantity
2
N/A
N/A
Motor Shaft Power
(4)
kW
5.5
N/A
N/A
Speed @ Maximum ESP
rpm
1196
N/A
N/A
Maximum ESP
Pa
322
N/A
N/A
Optional Fan - EC Motor
Centrifugal Backward Curved EC - Designed to 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
2.00
2.00
2.00
Motor Shaft Power
(4)
kW
N/A
N/A
N/A
Speed @ 25Pa / Maximum ESP
rpm
1895 / 2165
2135 / 2165
2135 / 2165
Maximum ESP
Pa
285
70
70
Low Pressure Hot Water
(5)
Copper Tube / Aluminium Fin
Capacity Gross
kW
30.0
31.5
31.5
Water Flow (Nominal)
l/s
0.67
0.70
0.70
LPHW Connection Sizes
mm
22
22
22
Technical Data Downflow Units X Type
Mechanical Data
DF35X - DF45X
