V20WX2-EZRE-2
V22WX2-EZRE-2
V26WX2-EZRE-2
Capacity
(1)
Nominal Cooling
kW
24.4
25.1
27.0
Total Heat of Rejection
kW
32.6
33.3
35.7
Capacity Steps
2
2
2
Dimensions - W x D x H
mm
1310 x 670 x 1940
1310 x 670 x 1940
1310 x 670 x 1940
Weight
(3)
kg
326 / 328
326 / 328
325 / 328
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour
Frame: Aluminium Frame With Aluminium Corners
Evaporator
Rifled Copper Tube / Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages
2/1
2/1
2/1
Condenser
Stainless Steel Brazed Plate
Water Volume
l
2.5
2.5
2.5
Evaporator Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed To 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
2
2
2
Motor Shaft Power
(4)
kW
N/A
N/A
N/A
Maximum ESP
Pa
203
55
55
Nominal Airflow
m³/s
1.70
2.00
2.00
Compressor - Scroll
Tandem
Quantity
2
2
2
Oil Charge Volume (Total)
l
2.40
2.40
2.40
Oil Type
Polyol Ester
Refrigeration
Single Circuit
Charge (Total)
kg
3.2
3.2
3.2
Connections
Water Inlet / Outlet
mm
28
28
28
Condensate Drain Hose
mm
19
19
19
Filtration
Disposable To BS EN 779 - G4 - 50mm
Quantity
3
3
3
OPTIONAL EXTRAS
Electric Heating (Total)
kW
15.0
15.0
15.0
Humidifier
Capacity
kg/hr
0.6 - 3.0
0.6 - 3.0
0.6 - 3.0
Feed/Drain
3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Condensate Pump
Head
m
8
8
8
Flow
l/m
5
5
5
Drain
10mm Stainless Steel Stub Connection
Optional Fan - EC Motor
Centrifugal Backward Curved EC - Designed To 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
1
1
1
Motor Shaft Power
(4)
kW
N/A
N/A
N/A
Speed @ 25Pa / Maximum ESP
rpm
1830 / 2165
2165 / 2165
2165 / 2165
Maximum ESP
Pa
285
25
25
Low Pressure Hot Water
(7)
Copper Tube / Aluminium Fin
Capacity Gross
kW
19.2
19.9
19.9
Water Flow (Nominal)
l/s
0.43
0.44
0.44
LPHW Connection Sizes
mm
22
22
22
Threaded Connection
Brass Male Taper
in
1
1
1
Technical Data Upflow Units WX Type
Mechanical Data
V20WX2 - V26WX2
