Page 72: Mechanical data v15x - v17x
EasiCool™
Precision Air Conditioning
72
EasiCool Technical Manual 7535776 V1.1.0_04_2013
Te
ch
ni
ca
l
X-
Ty
pe
V
380
V
6
0H
z
V15X-EZRE-1
V17X-EZRE-1
Standard Condenser Match
CR22
CR30
Capacity
(1)
Nominal Cooling
kW
16.7
18.7
Capacity Steps
1
1
Dimensions - Wx D x H
mm
990 x 670 x 1940
990 x 670 x 1940
Weight
(3)
kg
231
232
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour
Frame: Aluminium Frame With Aluminium Corners
Evaporator
Rifled Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages
1/1
1/1
Evaporator Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed To 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
1
1
Motor Shaft Power
(4)
kW
N/A
N/A
Speed @ 25Pa / Maximum ESP
rpm
N/A
N/A
Maximum ESP
Pa
127
42
Nominal Airflow
m³/s
1.20
1.40
Compressor - Scroll
Single
Quantity
1
1
Oil Charge Volume (Total)
l
1.66
1.89
Oil Type
Polyol Ester
Refrigeration
(5)
Single Circuit
Refrigeration Control & Type
Thermostatic Expansion Valve (Optional EEV) / R410A
Holding Charge
Inert Gas
Connections
Liquid (Sweat)
in
3/8
3/8
Discharge (Sweat)
in
5/8
5/8
Filtration
DisposableTo BS EN 779 - G4 - 50mm
Quantity
2
2
OPTIONAL EXTRAS
Larger Condenser Match
CR30
CR50
Nominal Cooling
kW
17.0
18.9
Hot Gas Reheat
(6)
Nom Heating (Gross)
kW
7.7
8.2
Electric Heating (Total)
kW
7.5
7.5
Humidifier
Capacity
kg/hr
0.6 - 3.0
0.6 - 3.0
Feed/Drain
3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Condensate Pump
Head
m
8
8
Flow
l/m
5
5
Drain
10mm Stainless Steel Stub Connection
Evaporator Fan Options:
Optional Fan - EC Motor
Centrifugal Backward Curved EC - Designed To 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
1
1
Motor Shaft Power
(4)
kW
N/A
N/A
Speed @ 25Pa / Maximum ESP
rpm
1330 / 1560
1560 / 1560
Maximum ESP
Pa
165
25
Low Pressure Hot Water
(7)
Copper Tube / Aluminium Fin
Capacity Gross
kW
12.7
13.7
Water Flow (Nominal)
l/s
0.28
0.31
LPHW Connection Sizes
mm
22
22
Technical Data Upflow Units X Type
Mechanical Data
V15X - V17X
