Page 164: Mechanical data v13wx - v17wx
EasiCool™
Precision Air Conditioning
164
EasiCool Technical Manual 7535776 V1.1.0_04_2013
Te
ch
ni
ca
l
380
V
6
0H
z
W
X - T
yp
e
V
22
0V
6
0H
z
V13WX-EZRE-2
V15WX-EZRE-2
V17WX-EZRE-2
Capacity
(1)
Nominal Cooling
kW
13.5
16.3
19.5
Total Heat of Rejection
kW
17.9
21.6
26.1
Capacity Steps
1
1
1
Dimensions - W x D x H
mm
990 x 670 x 1940
990 x 670 x 1940
990 x 670 x 1940
Weight
(3)
kg
234 / 235
265 / 267
268 / 270
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour
Frame: Aluminium Frame With Aluminium Corners
Evaporator
Rifled Copper Tube / Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages
1/1
1/1
1/1
Condenser
Stainless Steel Brazed Plate
Water Volume
l
1.4
2.0
2.5
Evaporator Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed To 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
1
1
1
Motor Shaft Power
(4)
kW
N/A
N/A
N/A
Maximum ESP
Pa
298
127
42
Nominal Airflow
m³/s
1.00
1.20
1.40
Compressor - Scroll
Single
Quantity
1
1
1
Oil Charge Volume (Total)
l
1.20
1.66
1.89
Oil Type
Polyol Ester
Refrigeration
Single Circuit
Charge (Total)
kg
2.1
2.6
2.6
Connections
Water Inlet / Outlet
mm
22
22
28
Condensate Drain Hose
mm
19
19
19
Filtration
Disposable To BS EN 779 - G4 - 50mm
Quantity
2
2
2
OPTIONAL EXTRAS
Electric Heating (Total)
kW
7.5
7.5
7.5
Humidifier
Capacity
kg/hr
0.6 - 3.0
0.6 - 3.0
0.6 - 3.0
Feed/Drain
3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Condensate Pump
Head
m
8
8
8
Flow
l/m
5
5
5
Drain
10mm Stainless Steel Stub Connection
Optional Fan - EC Motor
Centrifugal Backward Curved EC - Designed To 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
1
1
1
Motor Shaft Power
(4)
kW
N/A
N/A
N/A
Speed @ 25Pa / Maximum ESP
rpm
1125 / 1560
1330 / 1560
1560 / 1560
Maximum ESP
Pa
275
165
25
Low Pressure Hot Water
(7)
Copper Tube / Aluminium Fin
Capacity Gross
kW
11.5
12.7
13.7
Water Flow (Nominal)
l/s
0.26
0.28
0.31
LPHW Connection Sizes
mm
22
22
22
Threaded Connection
Brass Male Taper
in
3/4
3/4
1
Technical Data Upflow Units WX Type
Mechanical Data
V13WX - V17WX
