3-12
SERIES EL 071414
3.13.3 SCPI SUBSYSTEM COMMAND/QUERY STRUCTURE
Subsystem commands/queries are related to specific electronic load functions (such as setting
voltage, current limit, etc.) Figure 3-3 is a tree diagram illustrating the structure of SCPI subsys-
tem commands used in the EL Series Electronic Load with the “root” at the left side, and specific
commands forming the branches. The following paragraphs introduce the subsystems; subsys-
tem commands are defined and explained in Appendix B.
3.13.3.1 DIAGNOSTIC SUBSYSTEM
This subsystem is used to print the SCPI command set.
TABLE 3-2. REMOTE OPERATION COMMAND SUMMARY
Command Function
CONTROL COMMANDS. Terminate command with ? to display established mode.
MODE CURRent Enter Constant Current mode
MODE VOLTage Enter Constant Voltage mode
MODE POWer Enter Constant Power mode
MODE RESistance Enter Constant Resistance mode
MODE CONDuctance Enter Constant Conductance mode
MODE SHORt Enter Short mode
MODE OFF Disengage load and enable viewing of Model data.
INPut 1 or INPut ON (alternatively OUT 1) Engage load (load ON)
INPut 0 or INPut OFF (alternatively OUT 0) Disengage load (load OFF)
INPut:CUToff:TIME Establishes time to wait for input voltage to recover
after input is in Disabled state.
INPut:CUToff:VOLT Establishes minimum input voltage required for
engaging the load.
SET PARAMETER LEVEL COMMANDS. Terminate command with ? to display parameter level.
CURRent Set Current level in Amperes
VOLTage Set Voltage level in Volts
POWer Set Power level in Watts
RESistance Set Resistance level in Ohms
CONDuctance Set Conductance level in Siemens
CONDuctance:TRANsient ,,, Configures a transient conductance pulse.
CURRent:TRANsient ,,, Configures a transient current pulse.
RESistance:TRANsient ,,, Configures a transient resistance pulse.
VOLTage:TRANsient ,,, Configures a transient voltage pulse.
MEASUREMENT QUERIES.
MEASure:CURRent? Return Load current in Amperes
MEASure:VOLTage? Return Load voltage in Volts
MEASure:POWer? Return Load power in Kilowatts
MEASure:ALL? Return Load Power, Current and Voltage
