1-8 SERIES EL 071414
Dual Channel models are identified by a D Suffix. These models contain two identical indepen-
dent loads in one chassis.
1.10 SAFETY
There are no operator serviceable parts inside the case. Service must be referred to authorized
personnel. Using the load in a manner not specified by Kepco, Inc. may impair the protection
provided by the load. Observe all safety precautions noted throughout this manual. Table 1-6
lists symbols used on the electronic load or in this manual where applicable.
TABLE 1-5. ACCESSORIES
ITEM FUNCTION
KEPCO
PART NUMBER
Source Power cable Connects IEC 320-style power inlet connector with integral fuse holder
to 115V a-c via molded US line cord using 18AWG three conductor
jacketed cable with an insulation rating of 300 Volts for 115VAC input
voltage with polarized mating plug: 3 Amperes, 1 meter long. 118-1234
(Unicable 3850-761-BB/G
RJ 22 Master/Slave cable,
1 ft. (See Note.) Daisy chains Series EL loads with the same voltage for parallel config-
urations. 118-1245
Fuse 2.5A, SB (2) Two (2) required for units configured to run from a-c source power
above 200V a-c. 141-0136
(LittelFuse 21802.5HXP)
Slides (pair) Allows the unit to slide out of a rack. see PAR. 2.5.2.) CS 06
Side Support bracket Pair required. Used to provide side support for EL Load. Requires rear
rail at 18-13/16 in. setback. 128-1775
NOTE: For units that use slide mounting, consult Kepco for longer cable lengths.
TABLE 1-6. SAFETY SYMBOLS
SYMBOL MEANING
CAUTION: RISK OF ELECTRIC SHOCK.
CAUTION: REFER TO REFERENCED PROCEDURE.
WARNING INDICATES THE POSSIBILITY OF BODILY INJURY OR DEATH.
CAUTION INDICATES THE POSSIBILITY OF EQUIPMENT DAMAGE.
!
