GDS-1000 Series User Manual

76

Setup file format

Format

xxxx.set (proprietary format)
A setup file saves or recalls the following settings.

Contents

Acquire

mode

Cursor

source channel

cursor location

cursor on/off

Display

dots/vectors

grid type

accumulation
on/off

Measure

item

Utility

hardcopy type

language

ink saver on/off

Horizontal

display mode

position

scale

Trigger

trigger type

trigger mode

video polarity

pulse timing

source channel

video standard

video line

slope/coupling

Channel

(vertical)

vertical scale

coupling mode

bandwidth limit
on/off (GDS-
1102, GDS-1062)

vertical position

invert on/off

probe
attenuation

Math

operation type

vertical position

FFT window

source channel

unit/div
