GDS-1000 Series User Manual
102
Cursors and
Measurement Voltage Vpp, Vamp, Vavg, Vrms, Vhi, Vlo, Vmax,
Vmin, Rise Preshoot/ Overshoot, Fall
Preshoot/ Overshoot
Time Freq, Period, Rise Time, Fall Time, +
Width, – Width, Duty Cycle
Cursors Voltage difference (ΔV) and
Time difference (ΔT) between cursors
Auto Counter Resolution: 6 digits, Accuracy: ±2%
Signal source: All available trigger source
except the Video trigger
Control Panel
Function Autoset Automatically adjust Vertical Volt/div,
Horizontal Time/div, and Trigger level
Save/Recall Up to 15 sets of measurement
conditions and waveforms
Display LCD 5.6 inch, TFT, brightness adjustable
Resolution (dots) 234 (Vertical) x 320 (Horizontal)
Graticule 8 x 10 divisions
Display Contrast Adjustable
Interface USB Slave
Connector USB1.1 & 2.0 full speed compatible
(printers and flash disk not supported)
SD Card Slot Image (BMP) and waveform data (CSV)
Probe
Compensation
Signal Frequency range 1kHz ~ 100kHz adjustable, 1kHz step
Duty cycle 5% ~ 95% adjustable, 5% step
Amplitude 2Vpp±3%
Power Source Line Voltage 100V~240V AC, 47Hz~63Hz
Power
Consumption
18W, 40VA maximum
Fuse Rating 1A slow, 250V
Operation
Environment Ambient temperature 0 ~ 50°C
Relative humidity ≤ 80%, 40°C or below
≤ 45%, 41°C~50°C
Storage
Environment Storage temperature: -10°C~60°C, no condensation-
Relative humidity 93% @ 40°C
65% @41°C~60°C
Dimensions 341.5(W) x 162.3 (H) x 159 (D) mm
Weight Approx. 2.5kg
