CONFIGURATION

71

Manually triggering the signal

Note

This section describes how to manually trigger the
input signals when the oscilloscope does not
capture them. This section applies to the Normal
and Single trigger mode, since in the Auto trigger
mode, the oscilloscope keeps updating the input
signal regardless of the trigger conditions.

To acquire the
signal regardless
of trigger
conditions

To acquire the input signal
regardless of the trigger
condition, press the Force key.
The oscilloscope captures the
signals once.

FORCE

In the Single
trigger mode

Press the Single key to start
waiting for the trigger
condition. To break out of the
Single mode, press the
Run/Stop key. The trigger
mode changes to the Normal
mode.

SINGLE

Run/Stop
