Probe Specifications

GDS-1022/1042 Probe

Applicable model &
probe

GDS-1022,

GDS-1042

GTP-060A-4

Position x 10

Attenuation Ratio 10:1

Bandwidth

DC ~ 60MHz

Input Resistance

10MΩ when used with 1MΩ input

Input Capacitance 30pF approx.

Maximum Input
Voltage

300V peak
Derating with frequency

Position x 1

Attenuation Ratio 1:1

Bandwidth

DC ~ 6MHz

Input Resistance

1MΩ when used with 1MΩ input

Input Capacitance 200pF approx.

Maximum Input
Voltage

150V peak
Derating with frequency

Operating Cond.

Temperature

–10°C ~ 55°C

Relative

Humidity

≤85% @35°C

Safety Standard

IEC 1010-1 CAT II

GDS-1062/1102 Probe

Applicable model &
probe

GDS-1062

GTP-060A-2

GDS-1102
GTP-100A-2

Position x 10

Attenuation Ratio 10:1

Bandwidth

DC ~ 60MHz

DC ~ 100MHz

Input Resistance

10MΩ when used with 1MΩ input

Input Capacitance 23pF approx.

17pF approx.

Maximum Input
Voltage

500V CAT I, 300V CAT II (DC+Peak AC)
Derating with frequency

Position x 1

Attenuation Ratio 1:1

Bandwidth

DC ~ 6MHz

Input Resistance

1MΩ when used with 1MΩ input

Input Capacitance 180pF approx.

47pF approx.

Maximum Input
Voltage

300V CAT I, 150V CAT II (DC+Peak AC)
Derating with frequency

Operating Cond.

Temperature

–10°C ~ 55°C

Relative

Humidity

≤85% @35°C

Safety Standard

IEC 1010-1 CAT II

* Note: GW Instek reserves the right to change the probe model type (GTP-060A-2,
GTP-060A-4, GTP-100A-2) at anytime without notice for probe types of similar
specification.
