GDS-1000 Series User Manual

24

Math key 1/2

Math on/off

Math

Select math operation type (+/–)

Operation

Select addition/subtraction

CH1+/-CH2

Set result position

Position→VAR
Math result Volt/Div

Unit/Div→VAR

Math key 2/2

Math on/off

Math

Select math operation type (FFT)

Operation

Select FFT source channel

Source

Select FFT window

Window

Select FFT result position

Position→VAR
Select vertical scale

Unit/Div
