GW Instek SPD-3606 User Manual
Page 2
TABLE
OF
CONTENTS
3
Table of Contents
S
AFETY INSTRUCTION ..................................................... 5
O
VERVIEW ........................................................................ 9
SPD-3606 Main Features ...................... 10
Principle of Operation.......................... 11
Front Panel Overview ........................... 14
Rear Panel Overview ............................ 17
CV/CC Crossover Characteristics ......... 18
S
ETUP............................................................................. 19
Installation Location ............................ 20
Power Up ............................................. 21
Over Voltage Protection Setup ............. 22
Load Cable Connection ........................ 24
Output On/Off..................................... 25
O
PERATION .................................................................... 26
CH1/CH2 Independent Mode .............. 26
CH3 Independent Mode ....................... 28
CH1/CH2 Tracking Series Mode........... 30
CH1/CH2 Tracking Parallel Mode ........ 36
R
EMOTE OUTPUT CONTROL.......................................... 39
P
ERFORMANCE VERIFICATION ...................................... 40
Output Voltage Verification .................. 42
Tracking Series Voltage Verification...... 45
Output Current verification .................. 47
OVP verification ................................... 50
Recording Tables.................................. 54
SPD-3606 User Manual
4
F
AQ ................................................................................ 56
A
PPENDIX ...................................................................... 57
Fuse Replacement ................................ 57
Volume Guard (Optional)..................... 58
Specification ........................................ 59
Declaration of Conformity .................... 61
I
NDEX............................................................................. 62
