GDS-2000A Series Options Manual

48

3.3V CMOS

1.65V

2.5V CMOS

1.25V

ECL

-1.3V

PECL

3.7V

0V

0V

4. Press Threshold to set a user

defined threshold for the selected
input.

Range

±10V

Note

Setting the threshold levels from the Bus menu will
also change the threshold levels set in the Logic
Analyzer menu (page 38).

Bus Encoding

Background

The bus that is displayed on the screen or in the
event tables can be set to either hex or binary
formats.

Operation

Press Bus Display from the Bus
menu and choose either Hex or
Binary from the side menu.
