LOGIC ANALYZER

33

5. Press the Select soft-key again to

reduce the menu.

Note

Channels can also be selected just by turning the
variable knob when the mode is set to LA move mode.
In this mode the selected channel or group will be
shown on the Select soft-key. However this method
will only show those channels/groups that have
already been turned on. See page 33 for details.

Moving the Digital Channels or Creating Digital Channel Groups

Note

The digital channels must first be activated. See
page 31.

Background

The logic analyzer has two basic modes of
operation for selecting or moving digital channels.

LA Select mode: This mode is used to select digital
channels that have already been activated.

LA Move mode: This mode is used to move the
vertical position of the digital channels and to
group digital channels into groups.

The Select key is used to toggle between both
modes when in the D15~D0 On/Off menu.

Panel Operation

1. Press the D15~D0 On/Off key. The

scope will initially be in 'LA Select
mode'.
