Part No. 4801-5338 Rev 01-10 Evolution 4000 18 of 86
(17) Cool Timer: Cool timer is also allowed a
different timer cycle if needed. This can be used
for foggers or cool cell systems.
(18) Max Run - The Cool Timer Maximum Run Time
percentage.
(19) Cycle - Cycle Time in Minutes. Cool timer is
also allowed a different timer cycle if needed.
This will be used for foggers or cool cell systems.
(20) Min Run - The Cool Timer Minimum Run Time
percentage.
6.4 Stage Conditions – MAIN SYSTEM
When the Stage Conditions screen is selected by using the Navigator Select arrows, the following menu
screen is shown. Use the up and down arrows in the Editor to view the desired information. The listing
order from top to bottom is Inlet Stages, Feed, Light, or Aux Ventilation Stages. Notice that the Light
Clock and Feed Clock Stages are listed after the Inlet Conditions section. The Heat Stages are then
displayed in order of increasing ON Temperatures. The Cool stages, including the Variable Output stages,
are listed below the Target Line in order of increasing ON Temperatures.
