There are 8 main inputs with the Speedman that control external sensing functions.
All inputs are programmable to suit various applications.
They all require VOLTAGE FREE contacts and as such should NOT HAVE ANY VOLTAGE APPLIED.

All inputs operate on a CLOSED CONTACT for activation. This contact needs to be made between

the input common and the relevant input. There are three terminals for the input Common to allow for multiple
connections.

You can view which inputs are activated by accessing PUMP DATA LOG menu under the “Digital Input State”
screens. See PUMP DATA LOG for more information.

Each Input can now have inverted logic.
Normally if an input is connected via a switch or sensor between the input common and a programmable input
it is deemed to be ON and the input LED will be illuminated.
With inverted logic when an input is activated the controller will read this as OFF but the input LED will be
illuminated to indicate the actual state of the input. Inverted inputs have a number of uses and the main use
would be to provide fail safe activation of an input. Eg. If an programmable input is set to pause the system
on low level, then a normal input would provide an ON signal to pause the system, should that input be
disconnected or broken the system would not shut down resulting in damage to the pumps. If the input is
inverted the float can be wired to close the input connection for system run & open for system pause. (Fail
Safe)
To invert an input, firstly have the required input on the display, press the Enter button and then press the Up
& Down buttons simultaneously, the Input should now show (INV) on the top line. The change it back complete
the same procedure.

Programmable Input Options

Not Selected
When this is selected the input will not

Option

Delay time

Duration

1

Not selected

Instantaneous

Continuous

2

Set Point 2

1 second

Continuous

3

Set Point 3

1 second

Continuous

4

Set Point 4

1 second

Continuous

5

Set Point 5

1 second

Continuous

6

Set Point 6

1 second

Continuous

7

Set Point 7

1 second

Continuous

8

Set Point 8

1 second

Continuous

9

Soft Pause

1 second

Continuous

10

Soft Pause JP Run

1 second

Continuous

11

Emergency Stop

Instantaneous

Continuous

12

P1 Prot(Pause)

Input delay

Continuous

13

P2 Prot(Pause)

Input delay

Continuous

14

Pump 1 Stop

Instantaneous

Continuous

15

Pump 2 Stop

Instantaneous

Continuous

16

Pump 1 Manual Run

Instantaneous

Continuous

17

Pump 2 Manual Run

Instantaneous

Continuous

18

Fire Mode

1 second

Continuous

19

Cycle pumps

1 second

Rising edge

20

VFD Fault

1 second

Continuous

21

Reset

1 second

Rising edge

22

No Flow

Input delay

Continuous

23

Aux Input 1

Instantaneous

Continuous

24

Aux Input 2

Instantaneous

Continuous

25

Aux Input 2

Instantaneous

Continuous

26

Pump1 Fault(Stop)

Pump Fault Delay

Continuous

27

Pump2 Fault(Stop)

Pump Fault Delay

Continuous

28

Flow Pulse

Instantaneous

Rising edge

29

Low Level Pause

1 second

Continuous
