Davey Speedman Dual Pump Variable Speed Pump Control System - Manual (Page 3)

3
CONTENTS
INTRODUCTION 2
QUICKSTART 4
CANCELLING AUDIBLE BEEPER 6
PUMP CONTROL PANEL 7
MOVING AROUND & EDITING THE MENU ITEMS 8
MENUS 9
SYSTEM DISPLAY MENUS 18
FAULT HISTORY 18
PUMP DATA LOG 19
ACCESS CODE 21
SETTINGS 22
TUNING 26
TIMING 28
CONFIGURE 30
PUMP DEFINITIONS 35
JOCKEY PUMP 35
OUTPUTS 38
INPUTS 40
ANALOGUE INPUTS 45
PIPE FILL MODE 46
RESTORE OPTIONS 47
TIME OF DAY SET POINTS 47
PID CONTROL 51
PRESSURE TANK REQUIREMENTS 53
VSD SETTINGS 53
SPECIFICATIONS 55
TOP & BOTTOM CONNECTIONS TO SPEEDMAN CONTROLLER 56
TROUBLESHOOTING 57
INSTALLATION NOTES 58
INDEX 63
