17

Sub Menu

Units

Range

Defaults

RESTORE OPTIONS

CREATE BACKUP

*1

RESTORE BACKUP

*

These menus are related to other settings. They are not visible unless related settings are enabled.

*1

The Restore Backup menu item is only shown when there is a valid backup present.

Sub Menu

Units

Range

Defaults

OUTPUTS

Digital Output 1

selection

Jockey Pump

Run

Digital Output 2

selection

Any Pump

Shutdown

Any of the following can be selected on

any output and used multiple times

Shutdown Fault,

Lo Press Fault,

Hi Press Fault,

Any Alarm,

Pump 1 - 6 Run,

Pump 1 - 6 Fault,

System Paused,

Any Pump Shutdown,

Any Pump Running,

No Flow Shutdown,

VSD Fault,

Pressure Trip 1 - 2,

Alternate Trip,

Flow Trip,

Jockey PumpRun,

Aux Output 1 - 3,

Set Point Output 1-8

Analogue

Output 1

selection

VSD Speed.

VSD Speed

Analogue

Output 2

selection

VSD Speed, Flow Rate, System

Pressure

System

Pressure
